Description
Specification
Brand – OEM Quality
Shape of the contactor – Round shape 3
Maximum length of the contactor L1 (mm) – 67.5
Maximum width of the contactor W1 (mm) – 46
Maximum height of the contactor H1 (mm) – 80
Number of solenoids – 1
Voltage of the solenoid (V) – 12
Type of current – Direct current
Resistance of the solenoid (Ohm) – 10.5
Number of connections on the solenoid – 1
Type of connection on the solenoid – Wire with connector
Length of the cable of the coil L2 (mm) -130
Number of contact connections – 2
Type of contact connection – Outer thread
Outer thread size – M6
Pitch metric of outer thread (mm) -1
Right / left outer thread – Right-handed
Fuse present – NO
External diode present – NO
External resistor present – NO
Number of normal open contacts (NO) – 1
Auxiliary contact present – NO
Magnetic blow outs present – NO
Top cover – Closed
Shortest center distance between mounting holes C1 (mm) – 50
Number of closed holes – 2
Shape mounting surface – Flat
Support present – NO
Weight (kg) – 0.321
